Autoclaves

The YR06926 and YR06930 autoclaves feature chamber volumes ranging from Ø170×320 mm for the smallest model to Ø300×452 mm for the largest, enabling the sterilization of a wide variety of equipment and materials. With microprocessor control and a 4.3″ LCD touchscreen, these autoclaves provide easy operation and real-time monitoring of temperature, pressure, and sterilization time. Furthermore, their preset sterilization cycle, along with the ability to customize cycles and perform vacuum tests, offers flexibility to meet diverse user needs.

Design and Technology (Functionality)

The YR06926 // YR06930 autoclave stands out for its pulsating vacuum system, which ensures deeper and more uniform sterilization by eliminating any trace of air that could compromise the effectiveness of the process. Its SS304 stainless steel construction makes it durable, robust, and easy to maintain. Furthermore, the temperature accuracy of 0.1°C and thermal uniformity of ≤1°C guarantee consistent results. The vacuum level of -0.081 MPa ensures excellent air evacuation and improves the efficiency of the sterilization cycle.

Frequently Asked Questions

• What is the difference between the YR06926 and YR06930 models?The main difference lies in the chamber volume and product dimensions. The YR06926 is suitable for smaller volumes (8 liters), while the YR06930 offers a larger capacity (30 liters) for more demanding sterilization processes.
• Is this autoclave suitable for sterilizing medical instruments?Yes, this autoclave is designed to sterilize a variety of medical, laboratory, and research instruments, making it especially useful in clinics, hospitals, and research laboratories.
• Can I customize the sterilization cycles?Yes, the YR06926 // YR06930 allows for customization of the sterilization cycles, providing great flexibility according to the specific needs of the user.

Advantages and Disadvantages

Advantages:

• Reliable sterilization: Thanks to its pulsating vacuum system, it ensures complete elimination of microorganisms.
• Easy to use: The LCD screen and microprocessor control make its operation intuitive.
• Versatility: With different volumes, it is suitable for both small and medium-sized installations.
• Durability: Made of high-quality stainless steel, ensuring a long service life.

Disadvantages:

• Size: Although compact, models with higher capacity (such as the YR06930) may be bulkier and require more space in the laboratory or clinic.
• Initial cost: The price is competitive for a team in its category, but it is important to consider the initial investment.

Product Use in the Field

The YR06926/YR06930 autoclave is ideal for use in research laboratories , dental clinics , hospitals , pharmaceutical laboratories , and veterinary laboratories . Its ability to sterilize equipment of different sizes and types makes it an indispensable tool in the healthcare and scientific research sectors. In a clinical setting, it is commonly used for sterilizing surgical instruments , laboratory materials , and diagnostic equipment .

Recommendations

To maximize the performance and lifespan of the autoclave, the following is recommended:

1. Perform regular maintenance to ensure that autoclave components, such as seals and pressure valves, are in optimal condition.
2. Use appropriate sterilization cycles according to the type of material to be sterilized.
3. Do not overload the chamber to ensure that sterilization is effective on all objects.
4. Regular cleaning of the camera and exterior surfaces to prevent the accumulation of residue.

Technical Specifications
