Climate Chambers
A controlled climate chamber is a space where different environmental conditions are faked to determine the behavior of the material to be tested. The cameras offer a wide range of applications such as environmental simulation, accelerated aging, quality control, materials and systems research, product stability study, wet conditioning, behavior analysis of animal and plant species, among others.
Therefore, it means that the walk-in climate chamber, is that thermostatic unit of large dimensions, that a person can access. They are manufactured with special insulating panels, allowing to improve the weather conditions, generated inside the chamber. This type of climatic chamber is tailored to the measure, and each project is studied independently.
Types of weather chambers a laboratory may need
Artificial Climate Chamber
Climatic chambers are equipment or devices used in laboratories for the purpose of reproducing controlled conditions of temperature and humidity inside them for carrying out studies or tests, which verify the behavior and quality of products and materials exposed to such climatic conditions.
They are also known as controlled atmosphere cameras, as they can be modified depending on the needs that need to be covered by the operator. Among the parameters that can be modified or altered using these equipment we find: temperature, air circulation, and humidity. They can be used to perform the following tests: how to determine environmental effects on test samples, preparing samples for physical or chemical tests, and as an environmental condition simulator for conducting specimen tests.
Environmental Chamber
The stability chamber is a equipment that preserves samples, through studies involving climatic factors, as part of a productive or regulatory process. These studies are combined with variables such as lighting, temperature and humidity to define the conditions of stability and uniformity.
For this, the stability study climate chamber can be divided into constant climate chamber and variable climate chamber, and are used to diagnose the states of the samples at defined levels, and consequently, allows the pharmaceutical industries, expand the evaluations, to guarantee and monitor the state of the products.
In Kalstein you can find the ideal climate chambers for your laboratory
Constant Climate Chamber YR05334
LED large screen display working status at any time monitoring; adaptive control temperature constant; original imported temperature...
Comprehensive Drug Stability Test Chamber YR053286
Create a scientific method for the evaluation of drug failure for a long time to stabilize the temperature, humidity and light...
Strong Illumination Stability Test Chamber YR05353
Strong illumination stability test chamber for pharmaceutical companies to evaluation of drug failure, accelerated testing...
Illumination (Ray radiation) Incubator YR05331
Balanced refrigeration, automatic defrost, environmental protection without fluorineR134 refrigerant, LCD display...
Our Best Selling Climate Chamber
Quality compressor with delay protection function; no high efficiency fluorine coolant, more energy saving; built-in tempered glass display window and high capacity intelligent humidification systems; Single air circulation to ensure uniform temperature. Simulate the weather and the natural environment, day and night, control the temperature and humidity is a team.
Balanced cooling, automatic defrosting, fluorineR134 coolless environmental protection, LCD screen, intelligent PLD control by microcomputer, five adjustable lights, built-in tempered glass display door.
It is applied to the germination of plant seeds, planting, bacteria, microbes, animal and insect feeding, product quality testing and other light uses, constant temperature experiments. It is an ideal environment test equipment for biology, medicine, agriculture and livestock, forestry, research departments in environmental sciences
|
Product model
|
ALLIGENT-RG
Climate Simulation Chamber |
||
|
YR05347
|
YR05348
|
YR05349
|
|
|
Convection Mode
|
Forced Convection
|
||
|
Control System
|
Thirty stages Microprocessor PID controller
|
||
|
Temp. range
|
10~65℃(with lighting)/0~60℃(without lighting)
|
||
|
Temp. Accuracy
|
0.1
|
||
|
Temp. Fluctuation
（10-40℃） |
±1
|
||
|
Temp. Uniformity（10-40℃）
|
±1
|
||
|
Humidity Range
|
Humidity Range：50~90%RH，Humidity Fluctuation：±3%RH
|
||
|
Illumination Range
|
0~15000（five stages adjustable）
|
||
|
Timer Range
|
0～99 Hours，0～9999 minutes，can be choose
|
||
|
Working environment
|
Ambient temperature：10~30℃, Humidity<70%
|
||
|
Insulation materials
|
Imported environmental protection type material
|
||
|
External Dimensions (H×W×D)
|
1780×710×775
|
1780×770×815
|
1828×783×905
|
|
Internal Dimensions (H×W×D)
|
1100×480×480
|
1100×540×520
|
1148×554×610
|
|
Interior Volume(L)
|
250
|
300
|
400
|
|
Interior steel materials
|
Interior steel materials
|
||
|
Power Consumption (W)
|
1350
|
1350
|
1550
|
|
Power Supply
|
AC220V/50Hz
|
||
|
Net Weight (KG)
|
162
|
183
|
194
|
|
Shipping Weight (KG)
|
172
|
198
|
214
|
|
Shipping Dimensions (H×W×D)
|
1965×800×900
|
1965×860×940
|
2017×880×1060
|
