Description
- The fully automatic system features computer-controlled temperature regulation, temperature control devices, and an over-temperature protection mechanism for safe and efficient operation. Heating options include electrical, gas, steam, a combination of electrical and steam methods, or coal, allowing the operator to choose the most suitable option.
- Cooling fan is optimally designed for excellent heat dissipation and optimal wind speed. Both the drums and panels are constructed from stainless steel to prevent fabric contamination from corrosion. The design ensures easy accessibility to vital parts for straightforward maintenance and quick belt replacement. The large door opens 180 degrees, facilitating easy loading and unloading, with the option of left or right opening. This system is designed to work efficiently with gas heating.
Technical Specification
| Model | YR06311 |
| Capacity | 25KG |
| Drum Dimension | 4970*640 mm |
| Drum volume | 473 L |
| Motor Power | 0.75 Kw |
| Fan power | 0.75 Kw |
| Electric heating power | 24Kw |
| Steam pressure | 0.4-0.5Mpa |
| Voltage | 380V |
| Dimensions |
1060*1270*1860 mm
|
| Weight | 400Kg |
| Powered | GAS |
