Description
Soft touch user panel
Digital displays of kV, mAs and time
High frequency inverter type generator
Overload protection for kV, mA, Time and Temp
Self-manageable APR function with memory keys
Technical Specifications
| Model | YR06163 |
| Maximum output power | 20kW |
| Range of tube current | 32~320mA |
| Tube voltage range of radiography | 40kv~120kv |
| Range of exposure time | 10ms~5000ms |
| mAs range | 0.32mAs~320mAs |
| Input voltage range | AC 220V±22V |
| Communication interface | RS-232 |
| Other | Capacity lock automatically, fault diagnosis automatically, self-protection |
| Max. Tube voltage | 120kV |
| Focus | Small focus:1.0mm Large focus:2.0mm |
| Anode input power | Small focus:20KW Large focus:40KW |
| Anode speed | 2800 R/M |
| Target angle | 17.5° |
| Anode heat content | 100kJ(140kHU) |
