Description
- The fully automated system incorporates computer-controlled temperature regulation, temperature control devices, and an over-temperature protection mechanism to ensure safe and efficient operation. It offers various heating options, including electrical, gas, steam, a combination of electrical and steam, or coal, providing the operator with flexible choices.
- The cooling fan is expertly designed to provide superior heat dissipation and optimal wind speed. Both the drums and panels are made from stainless steel to protect fabrics from contamination and corrosion. The design allows easy access to essential parts for simple maintenance and quick belt replacement. The large door, which opens 180 degrees, makes loading and unloading easy, with options for left or right opening. This system is specifically designed to operate efficiently with gas heating.
Technical Specification
| Model | YR06319 |
| Capacity | 50kg |
| Drum Dimension | 1170*865 mm |
| Drum volume | 930L |
| Motor Power | 1.1 Kw |
| Fan power | 1.1Kw |
| Electric heating power | 46Kw |
| Steam pressure | 0.4-0.5 Mpa |
| Voltage | 380V |
| Dimensions |
1300*1570*2180 mm
|
| Weight | 510Kg |
| Powered | GAS |
