Description
- The fully automatic system incorporates computer-controlled temperature regulation, temperature control devices, and an over-temperature protection mechanism to ensure safe and efficient operation. It offers various heating options, including electrical, steam, a combination of electrical and steam methods, or coal, providing operators with the flexibility to choose the most suitable option.
- The cooling fan is expertly designed for superior heat dissipation and optimal wind speed. Both the drums and panels are made of stainless steel to prevent fabric contamination from corrosion. The design allows easy access to critical parts, making maintenance straightforward and enabling quick belt replacement. The large door, which opens 180 degrees, ensures easy loading and unloading, with the choice of left or right opening.
Technical Specification
| Model | YR06318 |
| Capacity | 50kg |
| Drum Dimension | 1170*865 mm |
| Drum volume | 930L |
| Motor Power | 1.1 Kw |
| Fan power | 1.1Kw |
| Electric heating power | 46Kw |
| Steam pressure | 0.4-0.5 Mpa |
| Voltage | 380V |
| Dimensions |
1300*1570*2180 mm
|
| Weight | 510Kg |
