Description
- The fully automated system includes computer-controlled temperature regulation, temperature control devices, and an over-temperature protection mechanism, ensuring safe and efficient operation. It offers various heating options such as electrical, gas, steam, a combination of electrical and steam, or coal, providing operators with the flexibility to choose the most suitable method.
- The cooling fan is engineered for optimal heat dissipation and wind speed, enhancing efficiency. Both the drums and panels are coated with a durable material to prevent corrosion and protect fabrics. The machine’s design ensures easy access to vital parts, making maintenance straightforward and allowing for quick belt replacement. The large door, which opens 180 degrees, makes loading and unloading convenient, with options for either left or right opening.
Technical Specification
| Model | YR06325 |
| Capacity | 70 kg |
| Drum Dimension | 1170*1125 mm |
| Drum volume | 1210 L |
| Motor Power | 1.1 Kw |
| Fan power | 1.5Kw |
| Electric heating power | 53 Kw |
| Steam pressure | 0.4-0.5 Mpa |
| Voltage | 380V |
| Dimensions |
1310*1830*2170 mm
|
| Weight | 580 KG |
| Powered | GAS |
