Description
Ultrasonic Cleaner Machine YR05234 Series Ultrasonic Cleaner Machine has a various capacity of internal operation, high cleaning accuracy.It can effectively clean the tiny dirt particles, and also clean the deep hole, the small seam and the workpiece concealment.
Product Features
- Proprietary MCU-sweep ultrasonic generator driver circuit to present better cleaning performance and to minimize noise level.
- Proprietary industrial ultrasonic transducer with high Q value and energy conversion efficiency and long service life.
- Imported high-strength glue, staple-free bonding, and long service life of tank.
- Mechanical timed cleaning for 1-60 mins and digital heating control, arbitrary set temperature up to 80 ℃.
- Internal tank fabricated of 1.0mm SUS304 stainless steel to present good performance and long service life.
- Cleaning basket made of 304 stainless steel and electro-polished.Outer Shell made of high-quality stainless steel to present good corrosion resistance.
Technical Specifications
Model | YR05234 | YR05235 | YR05236 | YR05237 | YR05238 |
Internal dimensions | 240*135*100 | 240*135*150 | 300*150*100 | 302*150*150 | 300*240*150 |
External dimensions | 268*170*243 | 268*170*290 | 325*178*243 | 325*178*290 | 368*270*290 |
Volume (L) |
3.2 | 5 | 4.8 | 6.8 | 11 |
Gross weight (KG) |
4.77 | 5.4 | 5.65 | 6.2 | 8.5 |
Ultrasonic Power (W) |
120 | 120 | 180 | 180 | 240 |
Power of heating (W) |
100 | 200 | 200 | 200 | 300 |
Drain valve | no | no | no | yes | |
Frequency (kHz) |
40 | ||||
Hour (Min.) |
1-60 | ||||
Heating Temperature (℃) |
30~80 |
Model | YR05239 | YR05240 | YR05241 | YR05242 | YR05243 |
Inner dimensions | 330*300*150 | 330*300*200 | 500*300*150 | 500*300*200 | |
External dimensions | 397*320*317 | 397*320*368 | 560*320*317 | 560*320*385 | |
Volume (L) |
15 | 20 | 22 | 30 | |
Gross weight (KG) |
11.5 | 12.5 | 14.5 | 16 | |
Ultrasonic Power (W) |
360 | 360 | 480 | 600 | |
Power of heating (W) |
400 | 400 | 500 | 500 | |
Drain valve | yes | yes | yes | ||
Frequency (kHz) |
40 | 28 | |||
Time (Min.) |
1-60 | ||||
Heating Temperature (℃) |
30~80 |
