Full-Automatic Chemiluminescent Immunoassay Analyzer YR06387

ManufacturerKalstein

Description

The Fully Automated Chemiluminescent Immunoassay Analyzer YR06387 is a cutting-edge device designed for high-efficiency diagnostic testing. This analyzer features a parallel testing system with 8 channels, allowing random combinations of test elements for greater flexibility. Thanks to CLEIA methodologies and magnetic separation, the YR06387 guarantees precise and reliable results. It is compatible with various types of samples, such as human plasma, serum, and urine, and can handle sample volumes between 30 and 200 µl, depending on the reagent used. The adjustable incubation temperature between 37 °C and 42 °C ensures adaptability to the specific requirements of each test. This versatile analyzer is ideal for clinical environments, providing accurate and timely diagnostic results.

Market Price

The Fully Automated Chemiluminescent Immunoassay Analyzer YR06387 is available on the market with a price range varying between $2,400 and $4,000 USD, depending on the configurations and additional options selected. To obtain a personalized quote and explore financing options, we invite you to request a quote through the Kalstein Plus platform.

Frequently Asked Questions

  • What types of samples can the YR06387 analyze?

The YR06387 is compatible with human plasma, serum, and urine, depending on the type of reagent used.

  • What is the data storage capacity of the analyzer?

The analyzer can store up to 100,000 entries of patient data, quality control, and calibration.

  • What methodology does it use to ensure accurate results?

The YR06387 uses CLEIA methodology and magnetic separation, guaranteeing precise and reliable results.

Advantages and Disadvantages

Advantages:

  • Fast performance: Provides precise results in a short period.
  • High precision: Uses CLEIA technology and magnetic separation to ensure reliable results.
  • Compatibility: Can analyze a variety of samples, including plasma, serum, and urine.
  • Easy interaction: Features an LCD touch screen for intuitive operation.
  • Large storage: Capacity to store up to 100,000 entries of patient data, quality control, and calibration.

Disadvantages:

  • Initial cost: The initial investment can be high.
  • Requires training: New users may need training to fully utilize its functions.

Field Use

The Fully Automated Chemiluminescent Immunoassay Analyzer YR06387 is ideal for clinical and research laboratories that require fast and accurate results. Its ability to deliver results in a short time makes it perfect for situations where time is crucial. Additionally, its integrated design that combines incubation, cleaning, and detection in one system facilitates continuous and efficient operation, reducing the need for multiple devices.

Recommendations

To maximize the performance of the Fully Automated Chemiluminescent Immunoassay Analyzer YR06387, regular maintenance is recommended, and the manufacturer’s instructions should be followed. Adequately train the staff to handle all the equipment functions and use high-quality reagents to obtain the best results. Additionally, take advantage of the storage capacity and flexible operation modes to optimize laboratory processes.

For more information and to request a personalized quote, visit our Kalstein Plus platform and get details on prices and financing options. Don’t miss the opportunity to improve efficiency and precision in your laboratory with the YR06387.

Technical Specifications

Model YR06387
Spectrum 300-650nm
Data Storage
– Patient data
>100,000 entries
– QC Data
>100,000 entries
– Calibration Data
>100,000 entries
Dimensions
320mm (W) x 550mm (D) x 550mm (H)
Weight 45kg (approx.)
Power Supply 100-240 Vac
Power Frequency 50Hz
Input Power 200VA
Printer Built-in
Computer Built-in
Screen
LCD touch-screen
Operation
24h operation (standby)
Recommended Use
Clinical environments

Additional information

Weight 52 kg
Dimensions 65 × 45 × 76 cm
