Description
All blood vessels less than 3mm is safely sealed during operation, and the maximum is up to 5mm.
With two output modes: MAX mode and MIN mode.
With foot switch and manual switch control modes.
Adopting quad-core CPU control and current closed-loop control technology, output amplitude is stable.
Adopting constant current tissue adaptive control technology, tracking tissue changes and outputting constant current to ensure constant amplitude.
Transducer automatic detection functions ensure high-efficient, stable and safe output.
Full touch screen control, activate and automatically clear the error prompt.
Intelligent monitoring functions such as opening and closing of jaw tools, connection reliability, pressure overload alarm, temperature overload alarm, etc.
Technical Specifications
| Model | YR06129 |
| Amplitude | 20um, 40um, 60um, 80um, 100um |
| Current | 180mA, 230mA, 280mA, 330mA, 380mA |
| Voltage | AC 190~240V |
| Frequency | 55.5KHz±1% |
| Maximum input current | 3.15A |
| Input power | 690VA |
| Maximum amplitude | 100um±1% |
| Maximum output current | 380mA±1% |
| Fuse | T3.15A, L250VP |
| Size (L*W*H) | 285mm*315mm*100mm |
