Forensic medicine has been constantly evolving since the 1800s. With technological advances, new tools have been developed that have helped to deepen the comprehensive study of physicochemical evidence, contributing greatly to the resolution of damaging and criminal cases. In this scenario, a new technological tool, known as an ion tester, is making waves in the scientific community for its great potential in forensic medicine.
Ion meters are digital measuring devices used to determine the concentration of ions in a liquid solution. These devices have been widely used in fields such as materials science and medicine. More recently, increasing attention has been paid to their utility in forensic medicine.
Types of Ion Meter a Laboratory May Need
Portable Ion Meter YR01817 // YR01817-15
Calibration from 2 to 5 points from low to high concentrations.Selectable concentration calibration points from 8, including ...
YR01816 Portable pH / Ion Meter
Multiparameter portable ion meter, 2 to 5 points calibration, selectable ion concentration units. The meter is suitable...
Our Best Selling Ion Meter
Multiparameter portable ion meter, 2 to 5 points calibration, selectable ion concentration units. The meter is suitable for measuring the pH, mV and ion concentration, accuracy: 0.5% F.S.
Ion Mode
• Multiparameter portable ion meter is equipped with a backlit LCD display.
• 2 to 5 points calibration, including the 8 concentration points can be selected.
• Direct ion concentration readout simplifies the measurement process.
• Automatic electrode diagnosis shows the calibration points and slopes.
• Selectable concentration units (ppm, mg/L, mol/L) and ionic valency.
| Model | YR01816 |
| pH | |
| Range | -2.000 to 20.000pH |
| Resolution | 0.001, 0.01, 0.1pH, selectable |
| Accuracy | ±0.002pH |
| Calibration Points | 1 to 5 points |
| pH Buffer Options | USA, NIST, DIN, 2 custom buffers |
| ORP | |
| Range | ±1999.9mV |
| Resolution | 0.1, 1mV, selectable |
| Accuracy | ±0.2mV |
| Calibration Points | 1 point |
| Measurement Modes | Relative or absolute mV |
| Ion Concentration | |
| Range | 0.001 to 19999 (deponding on the range of ISE) |
| Resolution | 0.001, 0.01, 0.1, 1 |
| Accuracy | ±0.5% F.S. (monovalent), ±1% F.S. (divalent) |
| Calibration Points | 2 to 5 points |
| Calibration Solutions | 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000 |
| Measurement Units | ppm, mg/L, mol/L, mmol/L |
| Temperature | |
| Range | 0 to 105°C/32 to 221°F |
| Resolution | 0.1°C/0.1°F |
| Accuracy | ±0.5°C/±0.9°F |
| Offset Calibration | 1 point |
| Calibration Range | Reading ±10°C |
| General Specifications | |
| Temperature Compensation | 0 to 100°C/32 to 212°F, manual or automatic |
| Stability Criteria | Low or high |
| Calibration Due Alarm | 1 to 31 days or off |
| Auto-Power Off | 10, 20 or 30 minutes after last key pressed |
| Memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | BNC, 3.5mm jack socket |
| Display | Custom LCD (80×60mm) |
| Power | 3×1.5V AA batteries or DC5V power adapter |
| Battery Life | Approximately 150 hours (turn off the backlight) |
| Dimensions | 170(L)×85(W)×30(H)mm |
| Weight | 300g |
Ion Meter Models Catalog on Sale
-
YR01816 Portable pH / Ion Meter
-
Portable Ion Meter YR01817 // YR01817-15
Select options This product has multiple variants. The options may be chosen on the product page
Guides to becoming an expert in Ion Meter
The Scientific Applications of Ion Meters in Water Industries: Safety and Evolution
Science has always played a vital role in the optimization and safety of our industries. One such technology, the...
The Scientific Applications of Ion Meters: Unraveling the Secrets of the Ionic World
In the last decade, science has experienced amazing technical advances fostered by the development of new technologies...
Ion Meter Applications in Anatomic Pathology: Expanding Scientific Horizons
Pathological anatomy is a medical discipline dedicated to the study of human diseases through the examination of cells and...
Scientific Applications of Ion Meters in Forensic Medicine – An Innovative and Effective Approach
Forensic medicine has been constantly evolving since the 1800s. With technological advances, new tools have been developed that have helped to deepen the comprehensive study of physicochemical evidence, contributing greatly to the resolution of damaging and criminal...
Videos of Ion meter
In this section you can find, our Ion meter running, packaged, receiving service, etc.
Ion Meter in operation
Science has always played a vital role in the optimization and safety of our industries. One such technology, the ion meter and its integration into the water sector, has revolutionized the way we manage our water resources. Ion meters, also called ionometers, are key instruments for measuring the activity of specific ions in a solution. In the water industry, these devices provide vital information about the quality and safety of the water we consume and use on a daily basis.
The instrument detects the concentrations of various impurities, such as metal ions, nitrates, fluoride, chlorides, among others. This ability to detect a variety of particles allows water industries to maintain the healthiness and suitability of water for human consumption and industrial applications.
