Turbidity meter
A Turbidimeter is a device used to measure the Turbidity of a liquid. This instrument is capable of measuring the size and concentration of particles in a suspension by scattering light in a tube. In other words, a turbidity meter determines how turbid a liquid is. This equipment consists of a light source, a cell to contain the sample and a light detector (photocell).
Turbidity is measured in NTU, which stands for Nephelometric Turbidity Units. A Turbidimeter measures the intensity of light scattered at 90 degrees when a beam of light passes through a water sample. The unit used in older times was the JTU (Jackson Turbidity Units), measured with the Jackson candle turbidimeter. This unit is no longer in standard use.
Types of Turbidy meter that a laboratory may require
Benchtop turbidity meter YR01842
Multiparameter benchtop turbidity meter with the Total Suspended Solids measurement mode, 2 to 7 points calibration...
Portable turbidity meter YR01841
High-performance portable turbidity meter, 2 to 5 points calibration, selectable 4 turbidity units. The meter is suitable...
Our Best Selling Turbidity Meter
Multiparameter benchtop turbidity meter with the Total Suspended Solids measurement mode, 2 to 7 points calibration, selectable 4 turbidity units. The meter is suitable for laboratory use.
Features
• Multiparameter benchtop turbidity meter is equipped with a 4.5 inches TFT display.
• 2 to 7 points calibration using the Formazin Standards.
• Selectable 4 turbidity units, including the NTU, FNU, EBC and ASBC.
• TSS conversion factor ensures the accurate measurement of the total suspended solids.
• Auto-Read function senses and locks a stable reading.
| Model | YR01842 |
| Turbidity | |
| Range | 0 to 2000 NTU, 0 to 500 EBC, 0 to 9999 ASBC |
| Resolution | 0.01 (0 to 99 NTU), 0.1 (100 to 999 NTU), 1 (1000 to 2000 NTU) |
| Accuracy | ±2% of reading (0~500 NTU), ±3% of reading (501~2000 NTU) |
| Calibration Points | 2 to 7 points |
| Calibration Standards | 0.02, 10, 200, 500, 1000, 1500, 2000 NTU |
| TSS | |
| Range | Deponding on the TSS conversion factor |
| Resolution | 0.1, 1 |
| Accuracy | ±3% of reading |
| General Specifications | |
| Light Source | Infrared-emitting diode (850nm wavelength) |
| Detector | Silicon photodiode |
| Stray Light | <0.02 NTU |
| Sample Volume | 30ml |
| Memory | Stores up to 200 data sets |
| Output | USB communication interface |
| Display | 4.5″ TFT LCD |
| Power | DC12V, using AC adapter, 220V/50Hz |
| Dimensions | 250(L)×177(W)×96(H)mm |
| Weight | 1.2kg |
| Order Code | Accessories |
|
YR01842
|
Turbidity standards 0.02, 200, 500, 1000 NTU |
| Glass sample vials | |
| Lint-free cloth | |
| DC12V power adapter |
Catalog of Turbidity Meters models on offer
Guides to becoming an expert in Turbidity Meters
Turbidity Control in Water Treatment
Turbidity meters are commonly used as part of water quality inspection to determine water resource protection...
Turbidimeter: operation
A turbidimeter is a laboratory device used to measure suspended particles in a liquid, that is, to measure their degree...
How is turbidity measured?
Turbidity is the measure of the opacity or cloudiness of a fluid, it is measured by specialized instruments called turbidimeters..
Advantages of using turbidimeter in the laboratory
Turbidimeters measure the intensity or attenuation of light that is transmitted through a liquid sample. The readings are reported in Nephelometric Turbidity Units (NTU), which correspond to the concentration of formazine that is used as a reference....
Video of our Turbidity Meter in operation
In this section you will find our Turbidity Meter in operation, packaged, being serviced, etc.
Turbidity meter in operation
To know the degree to which water loses its transparency, it is necessary and indispensable in the quality of drinking water; the measurement of turbidity requires the use of a light beam, this is known as the incident light beam, with defined characteristics, in order to determine the semiquantitative presence of particulate material present in water or any fluid sample.
When we filter water using any properly functioning filtration system, the turbidity of the effluent is monitored with a turbidity meter, this instrument has a beam of incident light that detects the material present in water, which causes the light beam to scatter and this scattered light detects and quantifies in relation to a traceable calibration standard.
Frequently Asked Questions about Turbidity Meters
How to know the prices of the Turbidity Meters?
To know the price of the Turbidity Meter we invite you to send us an email with your request through the contact form.
What are the lead times of the Turdibity Meters?
- If the equipment of your interest is in stock or if it must be manufactured.
- The type of freight you have chosen, this may be; air or sea.
How to make a purchase of Turdibity Meters?
- By email: sales@kalstein.eu
- By telephone: +33 (0) 1 78 95 87 02
- E-commerce: Via Kalstein's official website in your country.
How does the warranty work?
Can I request a quote online?
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
