Microscopes are essential equipment in any laboratory, some are very simple while others are more complex equipment; however, they are all made up of many parts that require proper maintenance, since they represent a large investment.
The first great advances in science and in particular in the biological sciences are due in part to the invention of the optical microscope, when at the end of the seventeenth century Anton van Leeuwenhoek, carving lenses, was able to appreciate the world that due to its small size was impossible see with the naked eye: the microscopic world.
Teaching Head, WF10x, WF16x, Quarduple, Ach. 4x10x40x100x, Mechanical Stage 115x125mm, Coaxial Focusing...
Double Layer Mechanical Stage 143*132mm, Upgradeable To 216x150mm,3W LED Kohler Illumination With...
Inclined 30°, rotatable 360°, interpupillary distance 48-75mm, high eyepoint eyepiece, which is convenient for people ...
Head Upgrade to large size with eyepiece tube dia.30.30mm,Eyepiece upgrade to dia.30mm Diopter adjustable...
| Model | YR0237 | YR0237-1 | |
| Head | Seidentopf Binocular Head, Inclined at 30°, Interpupillary Distance 52-75mm,Eyepiece Tubes Rotated 180° Up & Down | o | |
| Seidentopf Trinocular Head, Inclined at 30°, Interpupillary Distance 52-75mm,Eyepiece Tubes Rotated 180° Up & Down | o | ||
| Eyepiece | Wide Field Eyepiece WF10x/18mm | ||
| Objective | Infinite Semi-Plan Achromatic Objective 4x,10x,40x,100x | ||
| Nosepiece | Backward Quadruple Nosepiece | ||
| Stage | Double Layer Mechanical Stage, Size 140×140mm, Moving Range 75×50mm | ||
| Condenser | Sliding-in Center Adjustable Condenser N.A.1.25 | ||
| Focusing | Coaxial Coarse & Fine Adjustment, Moving Range 20mm | ||
| Illumination | S-LED Illumination, Adjustable Brightness | ||
| Laboratory Biological Microscope Optional Accessories | |||
| Eyepiece | WF10x/20mm, Diopter Adjustable | YR0237-1-op1 | |
| Objective | Infinity Plan Achromatic Objective 4x | YR0237-1-op2 | |
| Infinity Plan Achromatic Objective 10x | YR0237-1-op3 | ||
| Infinity Plan Achromatic Objective 40x | YR0237-1-op4 | ||
| Infinity Plan Achromatic Objective 100x | YR0237-1-op5 | ||
| Illumination | 6V20W Halogen Lamp, Brightness Adjustable | YR0237-1-op6 | |
| Dark Field | Dark Field Condenser, Dry, N.A.0.7~0.9 | YR0237-1-op7 | |
| Dark Field Condenser,Immersion, N.A.1.25~1.36 | YR0237-1-op8 | ||
| Dark Field Objective, Infinity Plan 100X, | YR0237-1-op9 | ||
| ForImmersion Dark Field Observation | |||
| Dark Field Objective, Infinity Plan 100X, With Iris Diaphragm | YR0237-1-op10 | ||
| ForImmersion Dark Field Observation | |||
| Phase Contrast | Infinity Plan Turret Phase Contrast Set | YR0237-1-op11 | |
| –Infinity Plan Turret Phase Contrast Condenser | |||
| –Ininity Plan Phase Contrast Objective 4x,10x,40x,100x | |||
| –Centering Telescope 10x | |||
| Infinity Achromatic Turret Phase Contrast Set | YR0237-1-op12 | ||
| –Infinity Achromatic Turret Phase Contrast Condenser | |||
| –IninityAchromatic Phase Contrast Objective 4x,10x,40x,100x | |||
| –Centering Telescope 10x | |||
| LED EPI-Fluorescent Kit | EPI Light 3W LED 465~475nm, B Excite Filter BP460~490 | YR0237-1-op13 | |
| EPI Light 3W LED 525~530nm, G Excite Filter BP510~550 | YR0237-1-op14 | ||
The optical microscope is a device that allows observing elements or structures that cannot be observed with the...
There are cells that when viewed under a microscope look transparent, in many cases, the use of staining...
The microscope is a device that allows observing elements or structures that cannot be observed with the naked...
The microscope is a piece of equipment through which we can observe elements or structures that cannot be....
Microscopes are essential equipment in any laboratory, some are very simple while others are more complex...
Optical microscopes have been used for centuries to look at very small objects with better resolution than the human...
They are a type of microscope, similar to conventional ones, however, they have a key difference, instead of ...
Optical microscopy is an indispensable tool for the microscopic study of matter. This technique is one of the oldest research projects in science and has played a crucial role in advancing the understanding of the nature of materials since ancient times...
In this section you can find, our Optical Microscope running, packaged, receiving service, etc.
The microscope is a computer through which we can observe elements or structures that cannot be observed with the naked eye, by using lenses, viewfinders and rays of light, which approach or enlarge the image at scales suitable for examination and subsequent analysis. As high precision instruments, it is necessary to emphasize their care and maintenance in order to maintain the integrity of each of its components.
As with any laboratory instrument, they must be adjusted for optimum performance, protected from damage and regularly maintained. The care of microscopes is particularly important in areas where dust is abundant, it is essential to cover them when they are not used, and when cleaning the soil, to avoid damage.
To know the price of the Microscopes we invite you to send us an email with your request through the contact form.
